| General Description |
CD Player, Digital-to-Analogue Converter |
| Finish |
Fine Textured Aluminium (Black / Silver) |
| Display |
POLED 128x64 pixels 2.7" |
| Standby Feature |
Yes |
| 12V Trigger |
Yes |
| CD Mechanism |
Slot-Loading |
| DSD Compatible |
Yes (DSD64 / DSD128 / DSD256) |
| Disc Compatibility |
CD/CDR |
| DAC |
ESS Sabre32 9018 chip |
| Resolution |
32 bits |
| Sampling Frequency |
Optical,Coaxial, AES: 32kHz - 192kHz
USB:32kHz - 384kHz(PCM) / DSD64, DSD128, DSD256 |
| Maximum Sampling Frequency |
Optical,Coaxial, AES: 192kHz
USB: 384kHz (PCM) / 11.2M (DSD256) |
| Digital Input |
2 x Coaxial, 2 x Toslink Optical, 1xAES/EBU, 1 x USB for PC USB, |
| Digital Output |
1 x Coaxial, 1 x Toslink Optical,1 x AES |
| Output Voltage |
4.2Vrms ±0.1 (Balanced)
2.1Vrms ±0.1 (Unbalanced) |
| Output Impedance |
10Ω |
| THD (1kHz 0dB 20Hz - 20kHz A wtd. |
<0.002% |
| Frequency Response +/-0.2dB |
20Hz - 20KHz (± 0.2dB) |
| Signal-to-Noise Ratio (S/N) A wtd |
RCA:<-98db xlr="" -100db="" td=""> |
| Dynamic Range (A wtd.) |
RCA:>98dB ,XLR>100dB |
| Crosstalk @1K |
RCA:<-120db xlr="" -130db="" td=""> |
| Gain Error |
<0.5W |
| Dimensions (H x W x D) |
80 x 444 x 317mm |
| Weight |
6kg |
