| Frequency Range (+/-3 dB) [Hz] |
29 - 160 |
| Maximum SPL [dB] |
115 |
| Crossover Frequency [Hz] |
40 - 120 |
| Low frequency driver, Quantity |
1 x 14" long stroke |
| Low frequency driver, Diaphragm type |
Aluminium |
| Enclosure type |
Bass Reflex |
| Bass Reflex Tuning Frequency [Hz] |
34 |
| Max. Amplifier Power Output [RMS watt] |
500 |
| Continous IEC Power Output [RMS watt] |
450 |
| Input Impedance [ohms] |
10k |
| Connection Input |
Mono (LFE)
RCA
Stereo (low-pass filtered) |
| Magnetic Shielding |
No |
| Recommended Placement |
Floor |
| Functions |
Crossover Frequency
Phase Switch
Standby (Auto Power) On/Off Switch
Volume (Gain) |
| Max. Power Consumption [W] |
650 |
| Dimensions With Base (HxWxD) [mm] |
429 x 396 x 428 |
| Weight [kg] |
26.4 |
| Accessories Included |
Manual
Remote Control
Spikes M8 |
