| HDMI-standard |
HDMI 2.0; High speed with ethernet |
|
| Cable configuration |
Single-Link |
|
| Connectors |
HDMI / HDMI |
|
| Directivity |
Equal in both directions |
| Areas of usage |
DVD, Bluray, TV, Projector, computer screen, etc |
|
| Maximal resolution |
4K Ultra - 4096 x 2160 @ 24 fps (Hz) |
|
| Cable strain relief |
Molded contact housing |
|
| Cross section area |
5 x TMDS 0.09 / 28 |
mm2 / AWG |
| Lead material |
Stranded oxygen-free copper |
|
| Di-electric (insulation) |
Air-injected PE foam |
|
| Inner Screen / Coverage |
Aluminized PET foil, 100 |
% |
| Commication leads / cross section / di-electric |
5 x / 0.081/28 / PE |
mm2 / AWG |
| Outer Screen, Coverage |
Aluminized PET foil and braid, 100 |
% |
| Jacket/Outer jacket trim |
Heat and age resistant PVC and nylon braid |
|
| Flame retardancy |
No |
|
| Cable outer dimension |
Ø 7 |
mm |
