Pro-Ject Phono Box E (valkoinen)
Pro-Ject Phono Box E (valkoinen)

Pro-Ject Phono Box E (valkoinen)

RIAA korjain MM-rasioille
Saatavuus
Varastossa
Saatavuustarkenne
Varastossa
Määrä
Laadukas ja edullinen RIAA.korjain MM-äänirasioille.
Tuotteen lisätiedot
75,00 €
MM äänirasioille
Laadukas ääni
Edullinen hinta
Lisää ostoskoriin

Phono Box E: Pure vinyl listening pleasure at an absolute bargain price!



Today, many amplifiers do not have a specific phono cartridge input. Phono Box E is an ideal phono preamplifier for these hifi systems. Phono Box E accepts MM cartridges and offers an audiophile music experience at an entry-level price. Advanced circuitry and SMD construction keep noise and distortion at a surprisingly low level. A built-in internal shielding and an outboard DC power supply leave no risk for external interference. Because of its small casing, Phono Box E can be placed near the turntable. Input and output sockets are gold-plated for preservation of quality. Phono Box E can be connected easily to a line-input (AUX etc) of your amplifier.



Amplification and RIAA equalisation for MM cartridges

• Design principle inspired by Dr. Sykora

• SMD circuitry

• Special low noise components

• Internal metal shielding

• Small size allows installation close to record player

• Gold plated RCA connection sockets

• Outboard power supply included



Technical specifications

Pro-Ject Phono Box E

Input impedance 47kohms
Input capacitance 120pF
Gain 40dB
Output voltage(typically) 500mV @ 1KhZ with 5mV input
Noise floor 88dB (A weighted)
THD <0,04%
RIAA equalisation accuracy 20Hz –20kHz (+0,5/ -,02dB)
Input 1 pair RCA socket
Output 1 pair RCA socket
Outboard power supply 18V/500mA DC; 220 - 240V, 50Hz
Standby power consumption < 1 watt
Power consumption 20mA DC
Dimension W x H x D (D with sockets) 120 x 32 x 100 (115)mm
Weight 250 g without power supply
