| Output power RMS / max. |
|
| - @ 4 Ohms |
2 x 280 / 560 Watts |
| - @ 2 Ohms |
2 x 490 / 980 Watts |
| Amplifier technology |
Ultra HD Class D |
| Inputs |
2 x RCA / Cinch
2 x Highlevel speaker input
1 x Optical SPDIF (28 - 96 kHz)
1 x Remote In
1 x Remote control input |
| Outputs |
2 x Speaker |
| Frequency response |
10 Hz - 40,000 Hz |
Bass boost
|
0 - 9 dB / 40 Hz - 120 Hz |
| Highpass |
15 Hz - 4,000 Hz adjustable |
| Lowpass |
15 Hz - 4,000 Hz adjustable |
| Bandpass |
15 Hz - 4,000 Hz adjustable |
| Slope high- / lowpass |
Butterworth 12 dB/Oct. |
| Distortion (THD) |
< 0,005 % |
| Signal-to-noise ratio |
105 dB (A-weighted) |
| Input sensitivity |
Highlevel 5 - 20 Volts
RCA / Cinch 2 - 8 Volts |
| Damping factor |
> 200 |
| Input impedance RCA / Cinch |
10 kOhms |
| Input impedance highlevel |
13 Ohms |
| Operating voltage |
10.5 - 16 Volts (max. 5 sec. down to 6 Volts) |
| Fuse |
3 x 30 A Maxi-fuse (APX) |
| Additional features |
ADEP circuit, remote control for volume
adjustment, Auto Remote switch, Input Mode switch, SPDIF Direct In switch |
| Dimensions (H x W x D) |
50 x 260 x 190 mm /
1.97 x 10.24 x 7.48”
|
